Troy-Bilt

SPRING - FORWARD CLUTCH Replaces Troy-Bilt part numbers: 1916712 1716712 732-04185

Complete kit to reshim the wheel shaft on any Horse model tiller. No substitutions. Contains: Part NumberTroy-Bilt Part NumberDescriptionQtyCP1166-11166-1Shim - Wheel Shaft ".062" thick2CP1166-21166-2Shim - Wheel Shaft ".030" thick2CP1166-31166-3Shim - Wheel Shaft ".015" thick2CP1166-41166-4Shim - Wheel Shaft ".010" thick6CP95019501Retaining Ring - Horse I & II tillers2CP95119511Retaining Ring - Horse III and Later tillers2CP96219609, 9621Wheel Shaft Seal - All Horse tillers2B12B12Wheel Shaft...

Wheel shaft shim set - any Horse model tiller. No substitutions. Contains: Part NumberTroy-Bilt Part NumberDescriptionQtyWSSI-21166-2Shim - Wheel Shaft ".030" thick2WSSI-31166-3Shim - Wheel Shaft ".015" thick2WSSI-41166-4Shim - Wheel Shaft ".010" thick6 ...

Driveshaft shim set - any Horse model tiller. No substitutions. Contains: Part Number   Troy-Bilt Part Number   Description  QtyCP1224-1      1224-1   Shim - Driveshaft ".010" thick   2CP1224-2      1224-2   Shim - Driveshaft ".030" thick   4CP1224-3      1224-3   Shim - Driveshaft ".005" thick   1 ...

Bronze worm gear - 30 tooth, 1.25" diameter - fits Horse Model tillers with TS-1 (1026A) tapered tine shaft. Comes with two shims (94017) for correct gear tolerance.  Other Parts that go with the Bronze Gear: Replacement 2675 gear uses CP97067 Key (.25 X 1.0). (The original gear used CP1104 Key-Woodruff that is .25 X 1.12)Use CP9618 tine shaft seals for the CP1026A tine shaft.If you need tine shaft shims, they are: CP1447-1 (1.775 X 1.375 X .0050) and CP1447-2 (1.775 X 1.375 X .010)...

GEAR - SPLINED - 16 TEETHFITS HORSE I SERIAL NUMBERS 1001-639999

CABLE-CONTROL FW MOWER - 21" LENGTH  - GENUINE TROY-BILT PARTNOTE: This cable has a "T" and "Z" end adjustable cable, if a mounting block & spring on it, if a  is needed, use 946-04026(746-04026).Replaces Troy-Bilt part numbers:746-0960946-0960 USED ON MODELS:12A-558Q40112A559B190 HW-65612A-568N190 HW-45612A-5691190 HW-65612B-5691190 HW-656

CAP SCREW - HEX HEAD - M8x1.25X10MM - Sicklebar Mower - Part was discontined in June 2012 FITS MODELS: 34032, 34033, 34034, 34035 (Serial numbers 340320100101 - 340320199999)

SHIM-1.125 X .671 X .048FITS TRAILBLAZER MODELS: 15003, 15003S, 15004, 15005, 34038, 34302, 34303, 34304S, 34305, 34307, 34308, 34309, 34339

BUSHING -FLYWHEEL

GRIP - HANDLEBAR - TRAILBLAZER - SICKLEBAR (Qty 1)

FLANGED BEARING - INCLUDES BRG #P406396FITS MODELS: 10721, 10789, 10790, 11307, 11310, 11397, 11420, 5018
