Troy-Bilt

BELT - DRIVE VARIABLE

FLAT IDLER PULLEY W/BEARING - MTD SELF-PROPELLED MOWERS

WASHER-1.75X.625X.

HEX HEAD SCREW 5/16"-18 X 1" Long - Neutral PlungerOTHER NEUTRAL PLUNGER PARTS: 1496 Neutral Plunger Spring (.78 X 2.125") 1035 Neutral Plunger9504 Neutral Plunger ClipCP9831 Locknut 3/8”-161902004 Neutral Plunger Bolt 3/8”-16X1.5 Low ProfileCP9801 Hex Nut 5/16”-18

HEX NUT 5/16"-18 - Neutral Plunger OTHER NEUTRAL PLUNGER PARTS: 1496 Neutral Plunger Spring (.78 X 2.125")1035 Neutral Plunger9504 Neutral Plunger ClipCP9831 Locknut 3/8”-161902004 Neutral Plunger Bolt 3/8”-16X1.5 Low ProfileCP9751 Hex Head Screw 5/16”-18

Hi-Pro Key 1/4" X 1 3/4" Connects the wheel shaft to clutch. Heavy-duty key for use with 1878 and 1879 wheel shafts.Some customers with July of 1972 and earlier tillers may need to use Hi-Pro key 9305 that is 1/4" X 1". Check your keyway to ensure proper fit.

IDLER ARM W/BUSHING (NLA)Replaces Troy-Bilt Part Numbers: 80063GW-T239700GW-T242201

KEY 3/16" SQ X 1" (Tiller Drive Shaft)

WASHER-LOCK

RIVETS - 5.3MM X 16MM

PIVOT PIN - OPC LEVER  Fits Horse OPC Serial #'s 120560100101 and up.

Retaining ring - heavy duty - Fits Horse tillers with serial number 600009 and up. Used with wheel shafts 1878 and 1879. Replaces Troy-Bilt part numbers: 9511GW-95119501GW-95011110
